Range of application:
■ Widely used in petroleum mining, oil refining, chemical industry, military industry and other dangerous environment for general lighting and operational lighting;
■ It could work in Zone 1 and Zone 2 of explosive gas environment;
■ It could work in Zone 21 and Zone 22 of flammable dust environment;
■ It could work for T1-T6(T5) of temperature group;
■ It could work for energy saving renovation projects and maintenance & replacement for difficult places;
■ It could work for places with high protection requirements and poor wet environment.
|
■ Product Parameters-8231 |
|
Item |
Symbol |
Description |
Unit |
|
Rated Voltage |
VOLT |
AC220 |
V |
|
Power |
P |
40-80 |
W |
|
Protection Level |
IP |
IP66 |
IP |
|
Lighting Angle |
θ |
120 |
° |
|
LED Qty |
/ |
100 |
PCS |
|
Base Specifications |
/ |
CREE3030 |
|
|
Anti-corrosion Grade |
/ |
WF2 |
|
|
Explosion Proof Grade |
/ |
Ex d IIC T6 |
|
|
Light Efficiency |
η |
120 |
Lm/W |
|
Frequency |
f |
50/60 |
Hz |
|
Power Factor |
PF |
＞0.95 |
PF |
|
Operating Temperature |
TOPR |
-20~40 |
℃ |
|
Storage Temperature |
TOPR |
-20~40 |
℃ |
|
Light Source |
/ |
led |
PCS |
|
Correlate Color Temperature |
Tc |
3000-6500 |
K |
|
Color Rendering Index |
CRI |
≥70 |
RA |
|
LED’S Operating Life |
LIFE |
100000 |
Hours |
|
Start-up Time |
T |
≤0.2 |
S |
|
Executive Standard |
/ |
GB3836.1、GB3836.2 |
|
|
Size |
/ |
Φ253×185 |
mm |
